Project : Case Study-33 | Bangalore, India | 2016
Details
Client: Case Study-33
Project Type: Analytical Laboratory & Sampling Test Laboratory
Year Completed: 2016
Location: Pharmaceutical R&D Facility
Scope: Detailed Utility Routing & Laboratory Engineering
Drawing Reference: DEN-A2-1631-401 Rev.08
Key Highlights
- Comprehensive laboratory utility routing
- Workstation-specific service distribution
- Integrated laboratory furniture coordination
- Utility point optimization for analytical equipment
- Overhead service routing for simplified maintenance
- Design developed in accordance with pharmaceutical laboratory engineering practices
Project Scope
- Utility routing for analytical laboratories
- Sampling laboratory utility planning
- Laboratory furniture service coordination
- Instrument utility point planning
- Utility distribution network design
- Construction & installation routing drawings
| Utility | Quantity |
|---|---|
| Purified Water (PW) | 18 Points |
| Compressed Air (CA) | 9 Points |
| Domestic Water (DW) | 15 Points |
| Clean Air (CLA) | 15 Points |
| Nitrogen (N₂) | 1 Point |
| Hydrogen (H₂) | 6 Points |
| Total Utility Connections | 64 Service Points |
| Parameter | Value |
|---|---|
| Analytical Laboratory | ≈2,650 sq.m |
| Sampling Laboratory | ≈662 sq.m |
| Total Laboratory Area | ≈3,312 sq.m |
| Total Area | ≈35,650 sq.ft |
Successfully delivered a coordinated utility routing design for Case Study-33's Analytical and Sampling Test Laboratories, integrating multiple laboratory services into a safe, maintainable, and operationally efficient infrastructure that supported analytical workflows and future laboratory expansion.
